| Processor |
Intel® Core™ M-5Y10 Processor (4M Cache, up to 2.00 GHz)
4.5W Fanless (TDP Nominal 4.5W, SDP 2.8W) |
| Chipset |
Intel® Broadwell Y |
| VGA Controller |
Intel® HD Graphics with DX 11.1 |
| Display |
Captative Touch Panel
10 points Capacitive Multi-Touch Win8.1 certifiable
11.6" (1920x1080; 16:9) FHD eDP Panel (optional)
11.6" (1366x768; 16:9) eDP Panel |
| EMR Touch (Option) |
Digitizer PEN Up to 2048 Pressure level |
| System Memory |
On board LPDDR3 DRAM with 1600 MT/s data rates up to 8G memory size for dual channel |
| Storage |
One 22mm*60mm or one 22mm*42mm size NGFF SSD slot
Supports 64GB/128GB/256GB |
| Internal MIC |
Analog mic |
| Speakers |
2 stereo speaker box |
| I/O Ports |
CTIA type Headphone out & mic input combo port (default)
OMTP type headphone out & mic input combo port (optional)
1x USB 3.0
1x DC-In Port
TF card
1x Micro HDMI Port, supports HDMI V1.4a, max data rate of 1.65Gb/s
21 pin Pogo pin connector for USB Keyboard cover or Multi function
docking station
Docking station function: 1xStandard HDMI Port, 4x USB2.0 port, 1x RJ45 Port, DC-In port, Support charging tablet on docking |
| Wireless LAN |
1 NGFF Slot for WIFI/BT card |
| 3G |
3G ULTRASTICK SLOT (optional): Support 1 huawei Ultrastick 3G card slot
3G+GPS +SIM SLOT (optional): Support 1 NGFF slot for M.2 3G card, 1 Micro-SIM card slot
4G+GPS+ SIM SLOT (optional): Support 1 NGFF card or other NGFF 4G card. 1 Micro-SIM card slot |
| Sensor |
Accelerometer
e-compass
Gyroscope (option)
Ambient light sensor (option)
All Sensor should meet Windows 8.1 Certifiable |
| Security |
AT
TPM2.0 Intel Firmware TPM (Option)
Secure Boot |
| Dock (optional) |
Docking station |
| Keyboard (optional) |
USB Keyboard cover |
| Digital camera |
2.0M Camera light sensor (Front)
5.0M Camera (Rear) |
| Power |
AC 110~240V, DC 12V @ 36W |
| Battery |
6000mAh Li-ion polymer Battery Pack |
| Dimension |
296.3(W)mm X 189.75(H)mm X 11.4(D)mm |
| Weight |
850g |
| Operation System |
Windows 8.1 |
