| Form Factor |
1U |
| Processor |
Processor Type:
IntelŽ XeonŽ processor E3-1200 v3 product family
IntelŽ XeonŽ processor E3-1200 v4 product family
Max. TDP Support: 95W
Number of Processors: 1 Processor |
| Dimensions |
W x H x D (inch)
17.2 x 1.7 x 32.0
438 x 43 x 813 |
| Chipset |
IntelŽ C226 |
| Storage |
2.5" Fixed
3.5" Fixed |
| Options |
Option 1: (12) 2.5" fixed SATA
Option 2: (12) 3.5" fixed SATA |
| Memory |
Total Slots: 4
Capacity: Up to 32GB ECC UDIMM
Memory Type: 1600/1333 MHz ECC UDIMM
Memory Size: 8GB, 4GB |
| Expansion Slot |
(1) PCIe Gen3 x8 LP MD-2 |
| Network Controller |
(1) IntelŽ 82599ES single port 10G SFP+
(4) IntelŽ I210 1 GbE
Dedicated 10/100 management port |
| Storage Controller |
(1) LSI 2008 SAS Controller |
| Power Supply |
(1) High efficiency 400W PSU, 80plus gold
(2) High efficiency 450W Redundant PSUs, 80plus gold |
| Onboard Storage |
(1) 2.5" fixed SSD (Not available in Redundant PSU SKU)
(1) SATADOM |
| Fan |
(5) System Fans |
| Video |
Integrated AST2300 with 8MB DDR3 Video memory |
| System Management |
IPMI v2.0 Compliant, on board "KVM over IP" support |
| Rear I/O |
(2) USB 2.0 ports
(1) VGA port
(1) RS232 serial Port
(4) 1 GbE RJ45 ports
(1) 10 GbE SFP+ port (Optional)
(1) dedicated 1Gb RJ45 management port |
| Operating Environment |
Operating temperature: 10°C to 35°C (50°F to 95°F)
Non-operating temperature: -40°C to 70°C (-40°F to 158°F)
Operating relative humidity: 50% to 90%RH
Non-operating relative humidity: 20% to 95%RH |
| TPM |
Yes (option) |
| Weight (Max. Configuration) |
15.4 (kg)
33.95 (lbs) |
