| Processor |
• Intel® Core™ i7-7700HQ processor (14nm, 2.8GHz, DDR4 2400MHz, 6MB Smart cache, TDP 45W)
• Intel® Core™ i5-7300HQ processor (14nm, 2.5GHz, DDR4 2400MHz, 6MB Smart cache, TDP: 45W) |
| Core Logic |
• Mobile Intel® HM175 Express Chipset |
| Display |
• 15.6” IPS (39.62cm) Ultra HD (3840x2160; 16:9) Crystal Bright Display
• 15.6” IPS (39.62cm) Full HD (1920x1080; 16:9) Crystal Bright Display |
| Memory |
• Dual channel DDR4
• Two 260 pins SODIMM sockets, support DDR4 2400 MHz (Real operation frequency depends on processor)
• Expandable memory from 8GB to 64GB, depends on 4GB/8GB/16GB SODIMM module |
| Video Controller |
• Intel® HD Graphics 630
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible
• NVIDIA® GeForce GTX 1060 (N17E-G1)
- 6GB GDDR5 Video RAM
- Support PCIe x16
- Microsoft DirectX® 12 compatible
- NVIDIA® PhysX®
- GeForce CUDA™ technology
• Microsoft Hybrid Graphics mode
• Support 4 active displays
• Support NVIDIA® Surround View via HDMI x1 and miniDP x2
• NVIDIA® GeForce GTX 1070 (N17E-G2)
- 8GB GDDR5 Video RAM
- Support PCIe x16
- Microsoft DirectX® 12 compatible
- NVIDIA® PhysX®
- GeForce CUDA™ technology
• Microsoft Hybrid Graphics mode
• Support 4 active displays
• Support NVIDIA® Surround View via HDMI x1 and miniDP x2 |
| Storage |
• One changeable 2.5” 7mm(H) HDD/SSD, SATA interface
• (Factory Option) One M.2 2280 SSD, SATA/PCIe Gen3x4 interface |
| Audio |
• High Definition Audio
• S/PDIF digital output
• Built in array microphone
• Built in two speakers
• Sound BlasterX® Pro-Gaming 360°
• ANSP™ 3D sound technology on headphone output |
| Keyboard & Pointing Device |
• Multi languages full color illuminated full size keyboard with numeric pad
• (Factory Option) Built in Secure pad or Touch pad with Microsoft PTP multi-gesture and scrolling function
• W/A/S/D gaming key |
| I/O ports |
• 2 x USB 3.1 Gen 2 port (Type-C)
• 3 x USB 3.0 ports (USB3.1 Gen1, 1 x powered USB port, AC/DC)
• 2 x Mini Display port 1.3
• 1 x HDMI™ output port (with HDCP)
• 1 x 2-in-1 Audio jack (Headphone / S/PDIF Optical output)
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC up to UHS-ll |
| Slot |
• Two or Three M.2 card slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface (A key)
- 2nd for SSD M.2 2280 Card with SATA / PCIe Gen3x4 interface (M key)
- (Factory Option) 3rd for LTE/UMTS/HSPA+ M.2 3042 Card with USB interface (B key) |
| Communication |
• Built in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory Option) Intel® Dual Band Wireless-AC 8265, 2x2 AC +BT M.2 2230 (Windstorm Peak)
• (Factory Option) Intel® Dual Band Wireless-AC 3168, 1x1 AC +BT M.2 2230 (Sandy Peak)
• (Factory Option) Qualcomm® Atheros Killer™ Wireless-AC 1535 Dual Band 2x2 AC +BT M.2 2230
• (Factory Option) UMTS/HSPA+ M.2 3042 Card module
• (Factory Option) LTE M.2 3042 Card module
• 2.0M FHD video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V, 7.89A, 150W
• Embedded 4 cells Polymer battery pack, 55WH
• Battery life: 295 minutes (with UMA mode, 55WH Battery) |
| Security |
• Kensington® Lock
• Intel® PTT for system without Hardware TPM
• (Factory Option) Area finger print
• (Factory Option) TPM 2.0 |
| Others Design |
• Metal (A/C/D)
• Shipping Mode
• FlexiCharger
• Virtual Reality ready
• Support Windows® 10 Cortana with Voice
• (Factory Option) USB drive |
| O/S Support |
• Windows® 10 (64-bit) |
| Certificate |
• Windows® 10 (64-bit) Logo
• HDMI™ Logo |
| Dimension |
• 380(W) x 252(D) x 18.6(H)mm |
| Weight |
• 1.95Kg, Including Barebone and 55WH Battery |
