| Processor |
• Intel® Core™ i7-8700K processor (14nm, 3.7GHz, DDR4 2666MHz, 12MB Smart cache, TDP: 95W)
• Intel® Core™ i7-8700 processor (14nm, 3.2GHz, DDR4 2666MHz, 12MB Smart cache, TDP: 65W)
• Intel® Core™ i5-8600K processor (14nm, 3.6GHz, DDR4 2666MHz, 9MB Smart cache, TDP: 95W)
• Intel® Core™ i5-8400 processor (14nm, 2.8GHz, DDR4 2666MHz, 9MB Smart cache, TDP: 65W)
• Intel® Core™ i3-8350K processor (14nm, 4.0GHz, DDR4 2400MHz, 8MB Smart cache, TDP: 91W)
• Intel® Core™ i3-8100 processor (14nm, 3.6GHz, DDR4 2400MHz, 6MB Smart cache, TDP: 65W)
• Support CPU over clocking depends on CPU SKU (Both of base frequency and ratio) |
| Core Logic |
• Intel® Z370 Express Chipset |
| Display |
• 17.3” (43.94cm) FHD (1920x1080) 16:9 panel, 4.0mm |
| Memory |
• Dual channel DDR4
• Four 260 pins SODIMM sockets, support DDR4 2400 MHz (Real operation frequency depends on processor)
• Expandable memory from 8GB to 64GB, depends on 4GB/8GB/16GB SODIMM module
• Support XMP 2666/3000 MHz
(XMP support depends on processor and works with 4 DIMMs dual channel or 2 DIMMs single channel) |
| Video Controller |
• NVIDIA® GeForce GTX 1060 OC (N17E-G1 OC)
- 6GB GDDR5 Video RAM
- Support PCIe x16
- Microsoft DirectX® 12 compatible
- GeForce CUDA™ technology
- MXM3.0
- NVIDIA® PhysX®
- Support 4 active displays
- Support NVIDIA® Surround View
- GPU over clocking |
| Storage |
• Two changeable 2.5” 7mm/9.5mm(H) HDD/SSD, SATA interface (RAID 0/1)
• (Optional) Two M.2 2280 SSD SATA/PCIe Gen3x4 interface (RAID 0/1) |
| Audio |
• High Definition Audio
• S/PDIF digital output
• Built in array microphone
• Built in two speakers
• Built in one subwoofer speaker
• Sound BlasterX® Pro-Gaming 360˚
• ESSTM SABRE HiFi DAC for high resolution headphone audio
• External 7.1CH audio output supported by 2-in-1 Audio, Microphone, Line-in and Line-out jacks |
| Keyboard & Pointing Device |
• Multi languages full color illuminated full size keyboard with numeric pad and anti-ghost keys
• Built in Secure pad with Microsoft PTP multi-gesture and scrolling function
• W/A/S/D gaming key |
| I/O ports |
• 4 x USB 3.0 ports (USB3.1 Gen1) (1 x powered USB port, AC/DC)
• 1 x USB 3.1 Gen2 port (Type-C)
• 1 x USB 3.1 Gen2 or (Configuration Option) Thunderbolt™ 3 combo port (Type-C)
• 2 x Mini DisplayPort 1.3
• 1 x HDMI™ output port (with HDCP)
• 1 x 2-in-1 Audio jack (Heandphone / S/PDIF optical output)
• 1 x Microphone jack
• 1 x Line-out jack
• 1 x Line-in jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC up to UHS-ll |
| Slot |
• Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 interface
-3rd for SSD M.2 2280 Card with SATA / PCIe x2 interface
|
| Communication |
• Built in Qualcomm® 10/100/1000Mb Base-TX Ethernet LAN
• (Factory Option) Intel® Dual Band Wireless-AC 8265, 2x2 AC +BT M.2 2230 (Windstorm Peak)
• (Factory Option) Qualcomm® Atheros Killer™ Wireless-AC 1535 Dual Band 2x2 AC +BT M.2 2230
• (Factory Option) Wireless LAN 802.11AD + Bluetooth v4.1 Combo M.2 2230 Card module
• 2.0M FHD video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19.5V, 11.8A, 230W
• Removable 8 cells Smart Lithium-lon battery pack, 82WH
• Battery life: 180 minutes (with NVIDIA® GeForce GTX 1060 OC, 82WH Battery) |
| Security |
• Kensington® Lock
• Area finger print
• TPM 2.0 |
| Others Design |
• Shipping Mode
• FlexiCharger
• Virtual Reality ready supported with processor i7/i5
• Support Windows®10 Cortana with Voice
• Killer DoubleShotTM Pro with KillerTM Wireless-AC 1535 module
• Intel® OptaneTM Technology
• (Optional) USB drive |
| O/S Support |
• Windows® 10 (64-bit) |
| Certificate |
• Windows® 10 (64-bit) Logo
• HDMITM Logo |
| Dimensions |
• 418(W) x 295.3(D) x 40.9(H) mm |
| Weight |
• 3.9Kg, Including Barebone, VGA card and 82WH Battery
|
