| Processor |
• Intel® Core™ i7-7700HQ processor (14nm, 2.8GHz, DDR4 2400MHz, 6MB Smart cache, TDP: 45W)
• Intel® Core™ i5-7300HQ processor (14nm, 2.5GHz, DDR4 2400MHz, 6MB Smart cache, TDP: 45W) |
| Core Logic |
• Mobile Intel® HM175 Express Chipset |
| Display |
• 17.3” (43.94cm) FHD (1920x1080; 16:9) Crystal Bright Display |
| Memory |
• Dual channel DDR4
• Two 260 pins SODIMM sockets, support DDR4 2400 MHz (Real operation frequency depends on processor)
• Expandable memory up to 32GB, depends on 4GB/8GB/16GB SODIMM module
• Support XMP 2666MHz (XMP support depends on processor and works in dual channel) |
| Video Controller |
• Intel® HD Graphics 630
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible
• NVIDIA® GeForce GTX 1060 (N17E-G1)
- 6GB GDDR5 Video RAM
- Support PCIe x16
- Microsoft DirectX® 12 compatible
- GeForce CUDA™ technology
- Battery Boost technology
• Microsoft Hybrid Graphics
• Support 4 active displays |
| Storage |
• One changeable 2.5” 9.5mm/7mm(H) HDD / SSD, SATA interface
• One M.2 2280 SSD, SATA or PCIe Gen3 x4 interface, Auto detection |
| Audio |
• High Definition Audio
• Built in array microphone
• Built in two speakers
• Sound Blaster™ Cinema 3 |
| Keyboard & Pointing Device |
• Multi languages white-LED illuminated full size keyboard with numeric pad
• (Factory Option) Full color RGB illuminated full size keyboard with numeric pad
• Built in touch pad with Microsoft PTP multi-gesture and scrolling function |
| I/O ports |
• 1 x USB 2.0 port
• 2 x USB 3.0 (USB 3.1 Gen 1) ports (Type A)
• 1 x USB 3.0 (USB 3.1 Gen 1) port (Type C)
• (Factory Option) 1 x USB 3.1 Gen 2 port (share with USB 3.0 port) (Type A) and 1x USB 3.1 Gen 2 port (share with USB 3.0 port) (Type-C)
(2 x USB 3.1 Gen 2 ports with 10Gb shared bandwidth)
• 1x Mini Display port 1.2
• 1x Mini Display port 1.3
• 1 x HDMI™ output port (with HDCP)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC |
| Slot |
• Two M.2 card slots
- 1st for WLAN Combo M.2 2230 Card with USB interface (A key)
- 2nd for SSD M.2 2280 Card with SATA / PCIe Gen3 x4 interface (M key) |
| Communication |
• Built in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory Option) Intel® Dual Band Wireless-AC 8265, 2x2 AC +BT M.2 2230 (Windstorm Peak)
• (Factory Option) Intel® Dual Band Wireless-AC 3168, 1x1 AC +BT M.2 2230 (Sandy Peak)
• 1.0M HD video camera
• (Factory Option) 2.0M FHD video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19.5V, 9.23A, 180W
• Removable 6 cells Smart Lithium-Ion battery pack, 62WH
• Battery life: 325 minutes (with UMA mode, 62WH Battery) (TBC) |
| Security |
• Security (Kensington® Type) Lock Slot
• Intel® PTT for system without Hardware TPM
• (Factory Option) TPM 2.0 |
| Others Design |
• Shipping Mode
• FlexiCharger
• Virtual Reality ready
• Microsoft Cortana with Voice Technology |
| O/S Support |
• Windows® 10 (64-bit) |
| Certificate |
• Windows® 10 (64-bit) Logo
• HDMI™ Logo |
| Dimension |
• 418.5 (W) x 288.7 (D) x 29.9 (H) mm (TBC) |
| Weight |
• 3.2 kg,including Barebone and 62WH Battery (TBC) |
