| Processor |
• Intel® Core™ i7-7820HK processor (14nm, 2.9GHz, DDR4 2400MHz, 8MB Smart cache, TDP: 45W)
• Intel® Core™ i7-7700HQ processor (14nm, 2.8GHz, DDR4 2400MHz, 6MB Smart cache, TDP: 45W)
• Support CPU over clocking depends on i7-7820HK |
| Core Logic |
• Mobile Intel® HM175 Express Chipset |
| Display |
• 17.3” (43.94cm) UHD (3840x2160) / FHD (1920x1080) 16:9 panel, 4.0mm |
| Memory |
• Dual channel DDR4
• Two 260 pins SODIMM sockets, support DDR4 2400 MHz (Real operation frequency depends on processor)
• Expandable memory from 8GB to 32GB, depends on 4GB/8GB/16GB SODIMM module
• Support XMP 2666 / 3000 MHz (XMP support depends on processor) |
| Video Controller |
• Intel® HD Graphics 630
- Dynamic frequency
- Intel Dynamic Video Memory Technology
- Microsoft DirectX® 12 compatible
• NVIDIA® GeForce GTX 1060 (N17E-G1)
- 6GB GDDR5 Video RAM
- Support PCIe x16
- Microsoft DirectX® 12 compatible
- NVIDIA® PhysX®
- GeForce CUDA™ technology
- GPU over clocking |
| Storage |
• One changeable 2.5” 7mm/9.5mm(H) HDD/SSD, SATA interface
• (Factory Option) Two M.2 2280 SSD, SATA interface (RAID 0/1) or One M.2 2280 SSD, PCIe Gen3x4 interface |
| Audio |
• High Definition Audio
• S/PDIF digital output
• Built in array microphone
• Built in two 2W speakers
• Built in one 4W subwoofer speaker
• Sound BlasterX® Pro-Gaming 720˚
• ANSPTM 3D sound technology on headphone output
• External 5.1CH audio output supported by 2-in-1 Audio,microphone and headphone jacks |
| Keyboard & Pointing Device |
• Multi languages white-LED illuminated full size keyboard with numeric pad
• (Factory Option) Multi languages full color illuminated full size keyboard with numeric pad
• (Factory Option) Built in Secure pad or Touch pad with Microsoft PTP multi-gesture and scrolling function
• W/A/S/D Gaming key on full color illuminated keyboard |
| I/O ports |
• 4 x USB 3.0 ports (USB3.1 Gen1, 1 x powered USB port, AC/DC)
• 1 x USB 3.0 (USB3.1 Gen1) port (Type-C) or (Factory Option) 1x ThunderboltTM 3 port
• 2 x Mini Display ports 1.3
• 1 x HDMITM output port (with HDCP)
• 1 x 2-in-1 Audio jack (Line out / S/PDIF Optical output)
• 1 x Microphone jack
• 1 x Headphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC up to UHS-ll |
| Slot |
• Three M.2 card slots
-1st for WLAN Combo M.2 2230 Card with PCIex2 and USB interface (A key)
-2nd for SSD M.2 2280 Card with SATA / PCIe Gen3x4 interface (M key)
-3rd for SSD M.2 2280 Card with SATA / PCIe Gen3x2 interface (M key) |
| Communication |
• Built in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory Option) Intel® Dual Band Wireless-AC 8265, 2x2 AC +BT M.2 2230 (Windstorm Peak)
• (Factory Option) Intel® Dual Band Wireless-AC 3168, 1x1 AC +BT M.2 2230 (Sandy Peak)
• (Factory Option) Qualcomm® Atheros Killer™ Wireless-AC 1535 Dual Band 2x2 AC +BT M.2 2230
• (Factory Option) Wireless LAN 802.11AD + Bluetooth v4.1 Combo M.2 2230 Card module
• 2.0M FHD video camera |
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V, 10.5A, 200W
• Embedded 4 cells Polymer battery pack, 66WH
• Battery life: 340 minutes (with UMA mode, 66WH Battery) |
| Security |
• Security (Kensington® Type) Lock Slot
• Intel ® PTT for system without hardware TPM
• (Factory Option) Area Fingerprint
• (Factory Option) TPM 2.0 |
| Others Design |
• Metal (A/C/D)
• Shipping Mode
• FlexiCharger
• Virtual Reality ready
• Support Windows®10 Cortana with Voice
• Intel® OptaneTM Technology
• (Factory Option) USB drive |
| O/S Support |
• Windows® 10 (64-bit) |
| Certificate |
• Windows® 10 (64-bit) Logo
• HDMI™ Logo |
| Dimension |
• 418.5(W) x 287(D) x 24.9(H)mm |
| Weight |
• 3.0kg, Including Barebone and 66WH Battery |
