| Processor / Core Logic |
• Intel® Core™ i7-4500U processor (22nm, 1.80GHz, DDR3L-1600MHz, 4MB L3 cache, TDP: 15W)
• Intel® Core™ i5-4200U processor (22nm, 1.60GHz, DDR3L-1600MHz, 3MB L3 cache, TDP: 15W)
• Intel® Core™ i3-4010U processor (22nm, 1.70GHz, DDR3L-1600MHz, 3MB L3 cache, TDP: 15W)
|
| Display |
• 14.0” (35.56cm) HD (1366X768) / HD+(1600X900) / FHD(1920X1080) 16:9, 3.2mm Panel
• Multi-touch |
| Memory |
• Dual channel DDR3L
• Two 204 pins SODIMM sockets, support DDR3L 1600MHz (Real operation frequency depends on processor)
• Expandable memory up to 16GB, depends on 2GB/4GB/8GB SODIMM module |
| Video Controller |
• Intel® HD Graphics 4400 (CPU for i7-4500U,i7-4200U, i3-4010U)
- Dynamic frequency
- Intel Dynamic Video Memory Technology up to 1.7GB
- Microsoft DirectX® 11 compatible |
| Storage |
• One 2.5" 7.0mm(H) HDD/SSD, SATA interface
• (Factory Option) mSATA SSD, SATA interface |
| Audio |
• High Definition Audio
• Built in array microphone
• Built in two speakers |
| Keyboard & Pointing Device |
• Multi languages A4 size isolated keyboard
• Built in touch pad with multi-gesture and scrolling function
|
| I/O ports |
• 2 x USB 3.0 ports
• 1 x HDMITM output port (with HDCP)
• 1 x Headphone jack
• 1 x Microphone jack
• 1 x RJ-45 LAN port
• 1 x DC-in jack |
| Card Reader |
• 6-in-1 Push-Push Card reader
- MMC / RSMMC
- SD / mini SD / SDHC / SDXC |
| Slot |
• Two Mini Card slots
- 1st for WLAN Combo Half size Mini Card with PCIe and USB interface
- 2nd for mSATA SSD Full size Mini Card with SATA interface
- (Factory option) 2nd for UMTS/HSPA+ Full size Mini-card with USB interface
|
| Communication |
• Built in 10/100/1000Mb Base-TX Ethernet LAN
• (Factory Option) Intel® Dual Band Wireless-AC 7260, 2x2 AC +BT HMC (Wilkins Peak)
• (Factory Option) Intel® Dual Band Wireless-N 7260, 2x2 AGN +BT HMC (Wilkins Peak)
• (Factory Option) Intel® Wireless-N 7260, 2x2 BGN+BT HMC (Wilkins Peak)
• (Factory Option) Intel® Dual Band Wireless-N 7260, 2x2 AGN HMC (Wilkins Peak)
• (Factory Option) UMTS/HSPA+ Full size Mini-card with USB interface
• 1.0M HD video camera
|
| Power Supply |
• Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 3.42A, 65W
• Removable 4 cells Smart Lithium-Ion battery pack, 44.6WH
• Battery life: 540 minutes (with 44.6WH battery)
|
| Security |
• Kensington® Lock
• (Factory Option) TPM1.2
|
| Other design |
• Painting
• Intel® Rapid Start Technology
• Intel® Smart Response Technology (depend on processor)
• Intel® Anti-Theft Technology
• Intel® Identity Protection Technology
• Intel® Smart Connect Technology
|
| OS Support |
• Windows® 8 (64-bit) |
| Certificate |
• Windows® 8 (64-bit) Logo
• HDMI Logo |
| Dimension |
• 340(W) x 240(D) x 22.8 (H)mm
|
| Weight |
• 2.0kg, including 44.6WH Battery |
