| PC (OPS) |
|
| Processor |
4th Generation Intel® Dual Core Processor |
| Chipset |
Intel® H81 Chipset |
| Memory |
Up to 16GB DDR3 1600MHz |
| Hard disk |
1x M-SATA, 1x Serial-ATA |
| Video card |
Intel® HD Graphics |
| Network card |
Intel® 1217V Gigabit LAN |
| Sound |
Integrated HD Audio CODEC with 6.0 Channels |
| Video ports |
Support up to 3x HDMI Ports & 2x HDMI Ports+DP Port (optional) |
| USB ports |
Supports up to 4x USB 3.0 Ports |
| Microphone input |
1 |
| Headphone output |
1 |
| Preposition USB-Touch |
1 |
| Preposition USB |
1 |
| WIFI |
Extensible 2.4G/5G, 150/300Mbps |
| Bluetooth |
Extensible |
| TOUCH SCREEN |
|
| Touch technology |
Infrared touch sensor |
| Inductive objects |
Finger, pen or any other non-transparent objects |
| Inductive size |
= Ø5mm |
| Touch points |
1, 2, 4, 6 points |
| Response time |
Single touch: Click: 8ms; Writing: 3ms
Multi-touch: Click: 8ms Writing: 8ms |
| Cursor speed |
300dots/second |
| Coordinate output |
4096×4096 |
| Positioning accuracy |
=±2mm |
| Communication interface |
USB (USB power supply) |
| Touch screen glass |
4mm, physical steel Mohs with 7-class explosion-proof glass, transmittance: >92% |
| Operating system |
Windows 7/8/10, XP, Win 2000, Linux, Mac, Android |
| Life time |
>60,000,000 times click at the same position |
| Anti-light test |
Filament lamp (220V,100W), the vertical distance is more than 350mm; The illuminance of sunlight is up to 90000Lux |
| DISPLAY PARAMETERS |
|
| Size |
55" |
| Panel |
TFT LCD with LED backlight |
| Active area |
1209.6mm(W) x 680.4mm (H)SS |
| Resolution |
1920x1080 |
| Brightness |
350cd/m2 |
| Contrast |
4000:1 |
| Display color |
1.06B |
| Response time |
6.5ms max |
| View angle |
Level and vertical 178° |
| Lifetime |
30000 hours |
| TV PARAMETERS |
|
| TV standard |
PAL/SECAM |
| Channels |
ATV(200CH) |
| Input impedance |
75 O |
| RF type of connection |
IEC |
| High-frequency interface |
1 |
| AV input (yellow) |
1 |
| AV output (yellow) |
1 |
| YPbPr (green blue red) |
1 |
| Multimedia interface |
2 |
| Multimedia interface |
2 |
| HDMI interface |
3 |
| VGA input |
1 |
| VGA Audio input |
1 |
| Audio output power |
8W+8W |
| Speaker |
2 |
| Surround |
Yes |
| Listen independant |
Yes |
| ELECTRICAL PARAMETERS |
|
| Input voltage |
100Vac~240Vac, 50/60Hz |
| Maximum Power Consumption |
150W |
| Standy by consumption |
<1W |
| MECHANICAL CHARACTERISTICS |
|
| Shell Material |
Aluminum alloy frame, Plastic rear cover |
| Frame size |
1296mm(W) x 729.8mm(H) x 81(D)mm |
| Packing size |
1425x970x210mm |
| Net weight |
40KG |
| Gross weight |
55KG |
