| Processor |
6th Generation Intel® Processor |
| Chipset |
Intel® Q170 vPro Chipset |
| Graphics |
Intel® HD Graphics |
| Memory |
2x SO-DIMM DDR4 2133 (up to 32G) |
| Storage |
Supports 7mm / 9.5mm 2.5“ SATA HDD / SSD
Supports M.2 SATA SSD (2280) |
| Ethernet |
Intel® I219LM Gigabit with vPro |
| Wireless |
M.2 (2230) Wi-Fi / Bluetooth combo slot
|
| Audio |
ALC233 codec |
| Power Adaptor |
19V 90W |
| Front I/O |
4x USB 3.0 / Audio output / MIC-in |
| Rear I/O |
DisplayPort / HDMI (4096×2160p@24Hz) / D-Sub
4x USB 3.0 / RJ45 / DC Jack / Line Out |
| COM / TPM |
1x COM header on rear I/O (Optional) / TPM software |
| Speaker |
Yes |
| LED Indicator |
Power LED / HDD LED |
| VESA Mount |
Supports VESA standard 100 x 100mm & 75 x 75mm |
| Kensington lock |
Supported |
| Dimensions |
178mm (L) x 178mm (W) x 34mm (H) without stand |
| Operating System |
Windows® 7 64-bit & 10 64-bit |
